Product Details: Professional 3-Axis Upgrade Kit for Laser Engravers

Unlock Ultimate Precision & Expand Your Creative Horizons

Tired of the limitations of your standard laser engraver? Our Professional 3-Axis Upgrade Kit is engineered to transform your machine from a basic tool into a powerhouse of precision and versatility. By adding a fully controllable Z-axis, this kit empowers you to tackle complex projects on irregular surfaces, achieve perfect focus every time, and automate production like never before.

Why Upgrade to a 3-Axis System?

A standard 2-axis engraver (X and Y) moves the laser head only horizontally. Our 3-Axis Kit introduces independent Z-axis control, allowing the laser head to move up and down with pinpoint accuracy during operation. This unlocks three critical capabilities:

1. Automatic Focus & Height Compensation: Engrave seamlessly on curved, sloped, or uneven objects (like mugs, rings, or phone cases) without manual adjustments or focus loss.

2. 3D Relief Engraving: Create stunning depth and texture by varying laser intensity with height, producing true 3D artwork on wood, acrylic, and leather.

3. Batch Processing Automation: Run unattended jobs on multiple objects of varying heights. The system automatically adjusts the Z-axis for each piece, maximizing efficiency.

Key Features & Benefits

• Plug-and-Play Compatibility: Designed for easy integration with popular desktop laser engraver models. Comprehensive mounting brackets and hardware included.

• High-Precision Lead Screw Drive: Our kit utilizes a durable, fine-pitch lead screw mechanism instead of a belt, ensuring rock-solid stability, minimal backlash, and micron-level accuracy for flawless results.

• Integrated Limit Switch: Features an auto-homing sensor for safe and precise initialization, protecting your machine and ensuring consistent starting points.

• Robust Aluminum Construction: The rail and carriage are built from lightweight yet rigid anodized aluminum, providing long-term durability without adding excessive weight or vibration.

• Seamless Software Integration: Works effortlessly with industry-standard software (LightBurn, LaserGRBL) and manufacturer OEM software. Simple configuration unlocks new G-code commands (G0, G1 on Z-axis) for full control.

Technical Specifications

• Travel Range (Z-axis): 100mm (Standard) / Customizable options available.

• Positioning Accuracy: ±0.02mm

• Drive System: T8 Precision Lead Screw

• Motor: High-Torque NEMA 17 Stepper Motor (included)

• Connector: Universal 4-pin JST (compatible with most control boards)

• Material: 6063 Anodized Aluminum Alloy

• Net Weight: Approx. 1.2 kg

Who Is This Kit For?

• DIY Enthusiasts & Makers: Take your personalized gifts, custom jewelry, and home decor projects to a professional level.

• Small Businesses & Startups: Increase your product range and offer premium 3D engraving services on challenging items.

• Prototyping Studios & Educational Labs: Perfect for creating detailed models, architectural reliefs, and teaching advanced digital fabrication concepts.

• Etsy Sellers & Crafters: Stand out from the competition with unique, textured products that command higher prices.

Package Includes:

1. Complete Z-axis Assembly (Rail, Carriage, Lead Screw)

2. NEMA 17 Stepper Motor with Pre-attached Cable

3. Mounting Bracket Set for Various Machine Models

4. Limit Switch & Sensor

5. All Necessary Screws, Wrenches, and Connectors

6. Detailed Step-by-Step Installation Guide (PDF/Video Link)

7. Basic Software Configuration Instructions

Invest in Precision. Expand Your Possibilities.

Don't let your creativity be limited by your tools. Our 3-Axis Upgrade Kit is the most cost-effective way to multiply the capabilities of your laser engraver. It's not just an accessory; it's a strategic upgrade for your hobby or business.
